Sony M60UI Marine head unit iPod control, USB, CD Receiver with Aux





GENERAL SPECIFICATIONS

Pre Out Output Level (V) 2
Pre Out Impedance (ohms) 220
Maximum Output Power (4Ω, 1kHz) (W) 52
Rated Output Power (W) 27
Conformal Circuit Board Coating Yes
Anti-Rust Reinforcement Yes
UV Resistant Yes
Weight (kg) Approx. 1.3 kg
Accessories RM–X151 Wireless Card Remote (Incl.) , RM-X60M / RM-X11M Wired Rotary Commander (Opt.)


DISPLAY PANEL

Display Device LCD Display
Panel Finish Colour White on Silver
Key Illumination Blue / Red

TUNER

Preset FM18 / AM12
FM: Tuning Range (MHz) 87.5-107.9, 87.5-108.0
MW: Tuning Range (kHZ) 531-1602, 530-1710
FM: Usable Sensitivity (75Ω) (dBf) 10
FM: Intermediate Frequency (MHz) 150KHz
FM: Selectivity (400kHz) (dB) 75
FM: S/N Ratio (Mono) (dB) 70
FM: Channel Separation (dB) 40
FM: Frequency Response (Hz) 20-15k


CD PLAYER

CD-Text Display / Scroll Yes
Multi Session MP3 / WMA / AAC
Frequency Response (Hz, dB) 10-20k, +/-1dB
S/N Ratio (dB) 120

AMPLIFIER

S-MOSFET Output Power 52W x 4
D/A Converter 24 bit
Pre Out x 2
Sub Out Yes
Aux-In Frontal Aux-In
USB Rear
Dynamic Soundstage Organiser 2 (DSO2) Yes
EQ3 Stage 2 (3-Band Equalizer / 7 Modes)
Bass Treble Low / Mid / High


IPOD CONTROL FEATURE

Repeat One, Album, Artist, Playlist, Genre, Podcast
Shuffle Genre, Album, Artist, Playlist, All, Podcast
Pause Yes
Resume Play Yes
CODEC (for iPod) MP3, AAC
List Browsing (Folders / Files) Yes
Passenger Control Yes
ZAPPIN™ Yes

USB

Repeat Off / Track / Folder
Shuffle Off / Folder / Device
Pause Yes
Resume Play Yes
CODEC (for USB) MP3, WMA, AAC
List Browsing (Folders/Files) Yes
ZAPPIN™ Yes





Sony MP1611 6 inch dual cone marine speakers



SPECIFICATIONS

Diameter 16cm
Speaker System Dual Cone
Peak Power (W) 140W
Rated Input Power (W) 40W
Frequency Response 40Hz - 20kHz
Sensitivity 90±2dB/W/m
Dimensions (φ x D) φ174 x 51
Weight Approx. 650g per speaker



Sony MP1621 6 inch 2 way marine speakers



SPECIFICATIONS

Diameter 16cm
Speaker System 2-Way Coaxial
Peak Power (W) 160W
Rated Input Power (W) 45W
Frequency Response 35Hz - 26kHz
Sensitivity 91±2dB/W/m
Dimensions (φ x D) φ174 x 61
Weight Approx. 850g per speaker
